Different Types Of CSA/ NEMA Receptacle (Non-Locking)
TT-30R
Description:
TT, 2-pole, 3-wire grounding
Voltage: 120V
Current: 30A
5-15R
Description:
5, 2-pole, 3-wire grounding
Voltage: 125V
Current: 15A
5-20R
Description:
5, 2-pole, 3-wire grounding
Voltage: 125V
Current: 20A
5-30R
Description:
5, 2-pole, 3-wire grounding
Voltage: 125V
Current: 30A
5-50R
Description:
5, 2-pole, 3-wire grounding
Voltage: 125V
Current: 50A
5-20RA ALTERNATE
Description:
5, 2-pole, 3-wire grounding
Voltage: 125V
Current: 20A
6-15R
Description:
6, 2-pole, 3-wire grounding
Voltage: 250V
Current: 15A
6-20R
Description:
6, 2-pole, 3-wire grounding
Voltage: 250V
Current: 20A
6-30R
Description:
6, 2-pole, 3-wire grounding
Voltage: 250V
Current: 30A
6-50R
Description:
6, 2-pole, 3-wire grounding
Voltage: 250V
Current: 50A
6-20RA ALTERNATE
Description:
6A, 2-pole, 3-wire grounding
Voltage: 250V
Current: 20A
7-15R
Description:
7, 2-pole, 3-wire grounding
Voltage: 277V
Current: 15A
7-20R
Description:
7, 2-pole, 3-wire grounding
Voltage: 277V
Current: 20A
7-30R
Description:
7, 2-pole, 3-wire grounding
Voltage: 277V
Current: 30A
7-50R
Description:
7, 2-pole, 3-wire grounding
Voltage: 277V
Current: 50A
24-15R
Description:
24, 2-pole, 3-wire grounding
Voltage: 347V
Current: 15A
24-20R
Description:
24, 2-pole, 3-wire grounding
Voltage: 347V
Current: 20A
24-30R
Description:
24, 2-pole, 3-wire grounding
Voltage: 347V
Current: 30A
24-50R
Description:
24, 2-pole, 3-wire grounding
Voltage: 347V
Current: 50A
14-15R
Description:
14, 3-pole, 4-wire grounding
Voltage: 125V / 250V
Current: 15A
14-20R
Description:
14, 3-pole, 4-wire grounding
Voltage: 125V / 250V
Current: 20A
14-30R
Description:
14, 3-pole, 4-wire grounding
Voltage: 125V / 250V
Current: 30A
14-50R
Description:
14, 3-pole, 4-wire grounding
Voltage: 125V / 250V
Current: 50A
14-60R
Description:
14, 3-pole, 4-wire grounding
Voltage: 125V / 250V
Current: 60A
15-15R
Description:
15, 3-pole, 4-wire grounding
Voltage: 3φ / 250V
Current: 15A
15-20R
Description:
15, 3-pole, 4-wire grounding
Voltage: 3φ / 250V
Current: 20A
15-30R
Description:
15, 3-pole, 4-wire grounding
Voltage: 3φ / 250V
Current: 30A
15-50R
Description:
15, 3-pole, 4-wire grounding
Voltage: 3φ / 250V
Current: 50A
15-60R
Description:
15, 3-pole, 4-wire grounding
Voltage: 3φ / 250V
Current: 60A
